JKO HM-4 HAUNCHER

Price

Contact us for price

orCall (828) 328-2641

Specifications

ManufacturerJKO
ModelHM-4 HAUNCHER
ConditionUsed
Serial Number2708
Stock Numbers-4806

Description

JKO HM-4 HAUNCHER S/N:2708, (220/440/60/3 electrics), S-4806 Standard Specifications: - Haunching spindle moves vertically up & down to stationary work-piece - 5.5 KW, 220/440/60/3 spindle motor, (belt driven) - 4-3/4" max. width of cut, (6-1/4" length of spindle including threads) - 1-1/4" diam. spindles - 2-1/2" min. & 9-3/4" max. cutting circles - 4-3/4" min. & 9-1/2" max. length of stroke, (spindle moves on linear rails) - 22" x 10-1/2" table size per side, (35" working height) - 1-3/8" front to back & +/-15 degree angular table adjustments - (1) pneumatic work-piece holddown clamp - Pneumatic foot pedal actuation - 6" diameter dust outlet - 4' x 4' x 5' approx. overall dimensions - Weighs approx. 1,000 lbs.
